Compact robotic palletizer for cases, crates and bags up to 60 kg — up to 1,200 loads/hour with 40+ layer patterns per recipe.
See it running
Live factory footage of the machine cycling at full rate. Videos are indexed for Google video search and can be cited by AI search engines, so engineering teams find the machine — and the proof — together.
The YM-980 is a four-axis or six-axis robotic palletizing cell that loads cases, crates and bags up to 60 kg onto pallets at up to 1,200 unit loads per hour. A vision-guided pallet-positioning system and layer-pattern recipe library (40+ patterns per SKU) keep changeover instantaneous. Its compact footprint fits where traditional high-level palletizers cannot, and the same cell can service two infeed lines or two pallet stations.
| Unit Load (kg) | up to 60 |
|---|---|
| Throughput (loads/hour) | 400 – 1,200 |
| Pallet Size (mm) | 800 – 1,200 x 800 – 1,200 (Euro, US, custom) |
| Max Pallet Height (mm) | 2,000 (incl. pallet) |
| Load Types | Cases, crates, shrink packs, bags, drums |
| Layer Patterns | 40+ per SKU recipe |
| Electrical Supply | 380V / 50Hz / 3-phase (option 460V / 60Hz) |
| Air Supply | 6 bar / 87 psi |
| Overall Dimensions (mm) | L 4,500 x W 3,200 x H 3,000 |
| Machine Weight (kg) | approx. 2,800 |
Yes. A dual-infeed configuration lets one robot alternate between two lines, balancing surge and reducing capital cost versus two dedicated palletizers.
Slip-sheet, layer-sheet and tie-sheet handling are offered as integrated options, with sheet feeding synchronized to the robot's layer cycle.
References where this machine architecture was specified.
Australia · 2025
A co-operative packaging 25 kg butter blocks needed a compact, hygienic erecting-packing-sealing cell that also handled chilled corrugate without condensation jams, plus palletizing in a freezer-adjacent hall.
Read the full story
Indonesia · 2026
A growing snack manufacturer needed to palletize both flexible bags and finished cases from three lines with a single operator, inside a limited warehouse footprint.
Read the full story
CADPalletizers
High-throughput gantry palletizer for heavy cases and multi-line operations — up to 1,800 loads/hour with twin gantry heads.
View machine detailsReady to engineer your line?
Send us your product dimensions, case size and target speed. You'll receive a machine layout, FAT plan and budgetary pricing within one business day.
